技术参数 Technical data | |
叶片长度 Blade length | 126m |
设计风场等级 Design type class | IEC S |
最大弦长 Max. chord length | 6.2m |
预弯 Pre-bending | 8m |
叶片预锥角 Pre-cone angle/can be different | 0° |
叶片重量 Mass without T-Bolt | 59t |
设计使用寿命 Design operation life | 25years |
材料体系 Material | E/H-玻纤增强环氧树脂E/H-glass reinforced Epoxy 碳纤维拉挤板Carbon Fiber Pultruded Plate |
运行参数 Operation Parameter | |
额定功率 Rated power | 12.x MW |
风轮直径 Rotor Diameter | 252m |
叶片数量 Number of blades | 3 |
功率控制 Power control | 变速变桨Pitchable & Variable-speed |
额定叶尖速度 Rated tip speed | 89.74m/s |
额定转速 Rated rotor speed | 6.8rpm |
******风能利用系数 Performance coefficient at TSR-opt | 0.485 |
根部连接 Blade Connection | |
螺栓类型 Principle | 预埋螺栓套/Insert |
螺杆中心圆直径 Bolt hole circle diameter | 4800mm |
螺栓数量和规格 Number, Size of tension bolts | 192xM39x4.0 10.9 |
根端外圆直径 Outer diameter of root | 4920mm |
